Additional Features:

• 10 kHz - 180 MHz or 300 MHz
• 0.04 ms/point measurement speed
• High speed filter and resonator evaluation using waveform analysis commands
• IBASIC for easy automation
• Phase Tracking Function for high speed evaluation of resonator (OPTION)
• Evaporation monitoring function (option)

The Agilent E5100A is a network analyzer best fitted for production lines of electronic component manufacturers, especially resonator and filter manufacturers, who require extra-high throughput. The Agilent E5100A improves production line productivity with its fast measurement speed (fastest sweep speed is 0.04 ms/point), fast waveform analysis commands, and high speed processor. It provides faster measurements with lower fluctuations because of its low-noise performance and fine selection IFBW.
